Oscillator 20

Frequency Range f 0 3 MHz to 100 MHz

Frequency Tolerance Δ f/f ±5PPM ~ ±50PPM at 25o C with 100μW

Frequency Stability Over OTR ±5PPM (Standard) From ±5PPM (depending on OTR)

Operating Temperature TOPR 0oC to 70o C Range

Load Capacity CL 6 ~ 100pF or series

Drive-Level DL 100.0μW Typ. 0.5mW Max

Shunt Capacitance C 7.0 pF Typ. .

Ageing Fa ±3.0 PPM / year
