LM393 Linear Hall Effect Sensor Module
The LM393 Linear Hall Effect Sensor Module is a compact magnetic field detection module designed to detect changes in the magnetic field around the sensor. It is suitable for Arduino, microcontroller, robotics, automation, and DIY electronics projects.
The module combines a Hall Effect sensing element with an LM393 comparator circuit, providing an easy-to-use interface for detecting magnetic field changes. The onboard adjustment potentiometer can be used to set the detection threshold on compatible module versions.
It can be used for applications such as magnetic object detection, position sensing, rotation detection, proximity detection, and speed measurement.
Key Features
- Hall Effect magnetic field sensor module
- LM393 comparator circuit
- Detects changes in magnetic fields
- Adjustable detection threshold on common module versions
- Compact PCB design
- Easy to interface with microcontrollers
- Suitable for Arduino and robotics projects
- Useful for rotation and position detection
- Suitable for DIY electronics and automation
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Hall Effect Sensor Module |
| Sensor Type | Hall Effect Magnetic Sensor |
| Comparator | LM393 |
| Detection | Magnetic Field |
| Output | Digital Comparator Output* |
| Sensitivity | Adjustable* |
| Interface | Sensor Module Output |
| Application | Magnetic Field & Position Detection |
| Suitable For | Arduino, Microcontrollers, Robotics & DIY Electronics |
*Exact output configuration and sensitivity characteristics can vary between module versions.
How It Works
The Hall Effect sensor detects changes in the magnetic field near the sensing element. When the magnetic field reaches the configured threshold, the module’s LM393 comparator changes its output state.
The output can then be connected to a digital input of a microcontroller to detect events such as the presence of a magnet, movement, rotation, or position change.
Applications
- Magnetic field detection
- Magnet detection
- Position sensing
- Proximity detection
- Rotation detection
- Wheel speed sensing
- Motor speed measurement
- Robotics
- Arduino projects
- Automation systems
- DIY electronics
- Educational electronics
Important Note
The exact operating voltage, Hall sensor characteristics, output logic, magnetic sensitivity, and detection distance can vary depending on the specific LM393 Hall sensor module version.
For accurate sensing applications, the sensor should be calibrated according to the magnet type, orientation, distance, and environmental conditions.
